M70L Electric Minivan

Vehicle Category

CATL Version
Pure Electric Panel Van

GOTION Version
Pure Electric Panel Van

Basic Parameters

Overall Length (mm)

4421

4421

Overall Width (mm)

1677

1677

Overall Height (mm)

1902

1902

Wheelbase (mm)

3050

3050

Curb Weight (kg)

1390

1430

Gross Weight (kg)

2550

2570

Seats No. (person)

2

2

Performance Parameters

Total Battery Storage (kwh)

41.86

39.9

Max. Speed(km/h)

≥80

≥80

Slope Climbing Requirement

≥20

≥20

Energy Density of Battery System (wh/kg)

≥125

≥125

Max. Range of Pure Electricity (km, VMAS)

≥280

≥261

Charging Time

Fast Charge 20-80%: 45min
Slow Charge 20-100%: 11-12h

Fast Charge 20-80%: 45min
Slow Charge 20-100%: 10-11h

Battery Type

LFP

LFP

Motor Type

Permanent Magnet Synchronous

Permanent Magnet Synchronous

General Configurations

Battery

CATL

GOTION(HeFei)

Driving Motor

INOVANCE

 FOUNDER

Motor Controller

 INOVANCE

 SUNGROW

Vehicle Control Unit

NLM

NLM

Cooling Mode of Motor Controller
(Water Cooling)

●

●

Cooling Mode of Motor Controller
(Air Cooling)

×

×

Battery Electric Heating System

●

●

Vehicle Monitoring System

●

●

Reversing Radar

●

●

Front Air Conditioner

●

●

Rear Air Conditioner

×

×

EPS

●

●

Slow Charge

●

●

Fast Charge

●

●

Inertial Valve (No ABS)

×

×

Load Sensing Valve (No ABS)

×

×

ABS

●

●

EBD

●

●

Front Door Power Window

●

●

Front Door Manual Window

×

×

Central Locking with Remote Control Key (Front and Middle Door)

×

×

Central Locking with Remote Control Key (Front, Middle and Tail Door)

●

●

Co-Driver's Auxiliary Handle

●

●

Co-Driver's Seat Adjustment
(Adjustable Forward and Rearward)

●

●

Second Row Hard Carpet

●

●

Third Row Hard Carpet

●

●

Second Row PVC Door Trim

●

●

PVC Interior Trim Panel at the Rear

●

●

Tail Door PVC Interior Trim Panel

●

●

Wheel

Aluminum Wheel 185/65 R15 LT

×

×

Steel Wheel 185/65 R15 LT

●

●

Wheel Cover (NLM LOGO)

×

×

Wheel Shaft Cover (NLM LOGO)

●

●

Spare Tire

Steel Wheel 185/65 R15LT

●

●
